Designed, Engineered & Manufactured in the U.S.A.

Hi-Flo II Side Discharge – 48-Frame Pump

The Hi-Flo II Above Ground pump was designed for superior performance. The Hi-Flo II pump features high flow rate performance for faster filtering cycles. This pump is ideal for new installations or as a replacement pump.

Features:

  • Intake - 1 1/2" Union, threads - 1 1/2" FPT
  • Discharge - 2" union, threads - 1 1/2" FPT
  • Large 6" pump trap with 2-piece lid
  • Wet end rotates for easy installation with either vertical or horizontal position
Pumps and replacement motors that are single speed and one (1) total HP or greater cannot be sold, offered for sale, or installed in a residential pool for filtration use in California, Title 20 CCR sections 1601-1609.

Hi-Flo II Side Discharge 48-Frame Above Ground Pool Pump and Trap

Part No.DescriptionVoltsHP SPLWeight (lbs.)
SD-07-1-T1 - Speed - 3 ft. twist-lock cord1151.03.99
SD-10-1-T1 - Speed - 3 ft. twist-lock cord1152.03.759
SD-07-1-N1 - Speed - 3 ft. NEMA cord1151.03.99
SD-10-1-N1 - Speed - 3 ft. NEMA cord1152.03.759
SD-07-2-T2 - Speed - 3 ft. twist-lock cord1151.06.158
SD-10-2-T2 - Speed - 3 ft. twist-lock cord1152.06.059
SD-07-2-N2 - Speed - 3 ft. NEMA cord1151.06.158
SD-10-2-N2 - Speed - 3 ft. NEMA cord1152.06.059
NOTE: for horizontal Hi-Flo, need to add a "-H" at the end.  1-speed pumps have an on/off toggle switch. 2-speed pumps have a hi/lo/off toggle switch included. NEMA cord is 3 prong grounded. All power cords are 3′ in length.
